Terminal Blocks

Sort By

woocommerce_catalog_ordering

Length

Width

Stud Spacing

Stud Size

Total Thickness

Amp Rating

Part # BAM/B-8

6-post Terminal Block, 100A, 95x60mm
$132.00

×

Amp Rating
100
Length (A) - mm
95
Width (B) - mm
60
Stud Spacing (C) - mm
35
Stud Size (D)
M8
Hole Distance (E) - mm
29-39
Thickness of Base (G) - mm
24
Length of Post (H) - mm
23
Total Thickness (L) - mm
47
Weight - lbs
0.66
Part # BAM/B-7

6-post Terminal Block, 100A,82x52mm
$90.00

×

Amp Rating
100
Length (A) - mm
82
Width (B) - mm
52
Stud Spacing (C) - mm
30
Stud Size (D)
M8
Hole Distance (E) - mm
25-34
Thickness of Base (G) - mm
19
Length of Post (H) - mm
23
Total Thickness (L) - mm
42
Weight - lbs
1
Part # BM/4

6-post Terminal Block, 15A, 54x34mm

×

Amp Rating
15
Length (A) - mm
54
Width (B) - mm
34
Stud Spacing (C) - mm
20
Stud Size (D)
M4
Hole Distance (E) - mm
20
Thickness of Base (G) - mm
15
Length of Post (H) - mm
12
Total Thickness (L) - mm
25
Weight - lbs
0.09
Part # BAM/B-10

6-post Terminal Block, 160A, 115x70mm
$246.00

×

Amp Rating
160
Length (A) - mm
115
Width (B) - mm
70
Stud Spacing (C) - mm
45
Stud Size (D)
M10
Hole Distance (E) - mm
40-47
Thickness of Base (G) - mm
22
Length of Post (H) - mm
28
Total Thickness (L) - mm
50
Weight - lbs
1.1
Part # BAM/B-3

6-post Terminal Block, 16A, 40x25mm
$30.00

×

Amp Rating
16
Length (A) - mm
40
Width (B) - mm
25
Stud Spacing (C) - mm
15
Stud Size (D)
M4
Hole Distance (E) - mm
12-18
Thickness of Base (G) - mm
10
Length of Post (H) - mm
10
Total Thickness (L) - mm
20
Weight - lbs
0.04
Part # BAM/B-4

6-post Terminal Block, 16A, 50x32mm
$36.00

×

Amp Rating
16
Length (A) - mm
50
Width (B) - mm
32
Stud Spacing (C) - mm
18
Stud Size (D)
M4
Hole Distance (E) - mm
15-21
Thickness of Base (G) - mm
10
Length of Post (H) - mm
12
Total Thickness (L) - mm
22
Weight - lbs
0.09
Part # BAM5

6-post Terminal Block, 25A, 56x36mm

×

Amp Rating
25
Length (A) - mm
56
Width (B) - mm
36
Stud Spacing (C) - mm
20
Stud Size (D)
M5
Hole Distance (E) - mm
20
Thickness of Base (G) - mm
13
Length of Post (H) - mm
15
Total Thickness (L) - mm
29
Weight - lbs
0.13
Part # BAM/B-5

6-post Terminal Block, 25A, 56x36mm
$36.00

×

Amp Rating
25
Length (A) - mm
56
Width (B) - mm
36
Stud Spacing (C) - mm
20
Stud Size (D)
M5
Hole Distance (E) - mm
16-23
Thickness of Base (G) - mm
12
Length of Post (H) - mm
15
Total Thickness (L) - mm
27
Weight - lbs
0.13
IF YOU CAN’T FIND A MOTOR PART, WE MAY BE ABLE TO HELP.
Ask Jenkins
Part # BAM/B-14

6-post Terminal Block, 298A, 145x90mm
$480.00

×

Amp Rating
298
Length (A) - mm
145
Width (B) - mm
90
Stud Spacing (C) - mm
54
Stud Size (D)
M14
Hole Distance (E) - mm
45-61
Thickness of Base (G) - mm
31
Length of Post (H) - mm
36
Total Thickness (L) - mm
67
Weight - lbs
2.5
Part # BAM/B-16

6-post Terminal Block, 315A, 165x100mm
$528.00

×

Amp Rating
315
Length (A) - mm
165
Width (B) - mm
100
Stud Spacing (C) - mm
62
Stud Size (D)
M16
Hole Distance (E) - mm
52-74
Thickness of Base (G) - mm
38
Length of Post (H) - mm
40
Total Thickness (L) - mm
78
Weight - lbs
3.5
Part # BAM/B-20

6-post Terminal Block, 400A, 240x150mm
$1,194.00

×

Amp Rating
400
Length (A) - mm
240
Width (B) - mm
150
Stud Spacing (C) - mm
90
Stud Size (D)
M20
Hole Distance (E) - mm
84-95
Thickness of Base (G) - mm
49
Length of Post (H) - mm
56
Total Thickness (L) - mm
49
Weight - lbs
8
Part # BM/6

6-post Terminal Block, 40A, 78x48mm

×

Amp Rating
40
Length (A) - mm
78
Width (B) - mm
48
Stud Spacing (C) - mm
28
Stud Size (D)
M6
Hole Distance (E) - mm
28
Thickness of Base (G) - mm
20
Length of Post (H) - mm
20
Total Thickness (L) - mm
36
Weight - lbs
0
Part # BAM8

6-post Terminal Block, 60A, 96x61mm

×

Amp Rating
60
Length (A) - mm
96
Width (B) - mm
61
Stud Spacing (C) - mm
35
Stud Size (D)
M8
Hole Distance (E) - mm
35
Thickness of Base (G) - mm
20
Length of Post (H) - mm
22
Total Thickness (L) - mm
40
Weight - lbs
0.55
Part # BAM/B-6

6-post Terminal Block, 63A, 70x45mm
$75.00

×

Amp Rating
63
Length (A) - mm
70
Width (B) - mm
45
Stud Spacing (C) - mm
25
Stud Size (D)
M6
Hole Distance (E) - mm
23-28
Thickness of Base (G) - mm
15
Length of Post (H) - mm
16
Total Thickness (L) - mm
31
Weight - lbs
0.26
Part # BAM/B-12

6-post Terminal Block,250A, 125x80mm
$350.00

×

Amp Rating
250
Length (A) - mm
125
Width (B) - mm
80
Stud Spacing (C) - mm
45
Stud Size (D)
M12
Hole Distance (E) - mm
40-49
Thickness of Base (G) - mm
26
Length of Post (H) - mm
32
Total Thickness (L) - mm
58
Weight - lbs
1.68
Part # BAM/B-94

9-post Terminal Block, 16A, 40x40mm
$84.00

×

Amp Rating
16
Length (A) - mm
40
Width (B) - mm
40
Stud Spacing (C) - mm
15
Stud Size (D)
M4
Hole Distance (E) - mm
13-17
Thickness of Base (G) - mm
11
Length of Post (H) - mm
10
Total Thickness (L) - mm
21
Weight - lbs
0.09
Part # BAM/B-96

9-post Terminal Block, 63A, 65x65mm
$102.00

×

Amp Rating
63
Length (A) - mm
65
Width (B) - mm
65
Stud Spacing (C) - mm
25
Stud Size (D)
M6
Hole Distance (E) - mm
25
Thickness of Base (G) - mm
15
Length of Post (H) - mm
16
Total Thickness (L) - mm
31
Weight - lbs
0.35

IF YOU CAN’T FIND A MOTOR PART, WE MAY BE ABLE TO HELP.
